Schiumvel

Technical datasheet

General description

Water-based foaming concentrate for leak testing – pressure method.

Packaging

10 l cans

Part Number: 02098120

In Compliance with

ASME Sect. V Art. 10 – Appendix I-II
EPA Part 60, Appendix A, Method 21, Sect. 4.3.3

Features

Easy to use.
Free from silicones, oils, fats, aliphatic amines, and other nitrogen compounds.
Excellent foam generation capability.
Excellent detection of both large and small leaks.
Prolonged bubble action works even on very small leaks and vertical surfaces.

Product Properties

Appearance	Colorless transparent liquid
Density at 20°C	≈1,0 g/cm³
Solubility	Water

User Recommendations

NDT Method	Leak Testing
Shelf life	3 years at T between 5°C and 45°C
Usage temperature	From 4°C to 52°C
Dilution	30-50%
Preliminary cleaning	Velnet/Solnet
