Author: Lorenzo Fabbri

Happy Birthday President!

CGM’s wanted to honour their President Giorgio Savasta on his birthday by organising a warm-hearted surprise party: we were all together celebrating  him , it was touching to see him moved by the affection and gratitude shown.

As our Captain, we decided to celebrate giving him a symbolic present with a nautical theme, thanking him for being our Commander, who always guided our ship into safe harbour.

Wishing all the best for your birthday!

Continue reading

CGM Running Team at Milano Marathon 2024

After last year’s success, Running Team CGM took place again at the starting line of the Relay Milano Marathon 2024 on Sunday 7 April, full of enthusiasm and a desire to have fun.

Our acclaimed champions, already authors of last year’s adventure, Anna Mori, Ramona Tiengo and Eugenio Feneri, once again competed in the relay race, joined this year by our new Technical Office Manager Giuseppe Melis, replacing Michele Burei; he temporarily gave up the relay race for this occasion in order to achieve an even more ambitious goal: complete the 42 km route alone!

Obviously, ours achieved their respective goals with their usual stubbornness and tenacity, contemptuous of the fatigue and heat that hindered them: our relay runners finished the race in 5 hours and 6 minutes, while Michele completed the titanic task in 4 hours and 6 minutes.

However, beyond this purely and sporting aspect, CGM has once again committed itself to supporting the charitable initiatives, which characterizes the event. We have decided to renew our commitment to the Dynamo Camp Foundation, which has been dedicated for years to offering specific Recreational Therapy programs free of charge to children and adolescents suffering from chronic illnesses – either in therapy or in the post-hospitalization period – to restore their self-confidence and their abilities, trying at the same time to improve the quality of life of their families.

Having fun does not mean only this: we do not want to forget initiatives aimed at improving our society and, as far as possible, we want to offer our concrete contribution, always aware of the importance of solidarity, especially considering the times we are all living in.

Anyway: once again, congratulations guys! Not only for representing our company in the best possible way, but for once again bringing a smile to people in need. We are all very proud of you!

But now the time for celebration is over: Marathon 2025 is coming up and you cannot be caught unprepared!

Continue reading

Detergent Type 149

Technical datasheet

General description

Detergent type 149 is a colourless, slightly acidic degreasing cleaner for spray, immersion or ultrasonic applications. Suitable for all metals, in particular where objects made of different metals or alloys are to be degreased. Suitable for removing mineral oil residues. Low environmental impact.

Packaging

25 l cans

Part Number: 02011005

Product Properties

Appearance Transparent liquid
pH

(Sol. acq. 2%)
  6,2 ± 0,5

User Recommendations

NDT Method

Liquid penetrant inspection

Usage temperature

Up to 60°C

Usage concentration

From 2 to 5%

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Related products

Continue reading

Detergent Type Clean 84 HD

Technical datasheet

General description

CLEAN 84 HD Type Detergent is a slightly alkaline amber-coloured liquid cleaner used especially for ultrasonic cleaning baths. Suitable for polished articles of brass and zinc alloys, copper and its alloys, precious metals and light alloys. it can be used in multiple sectors. Particularly useful in cases where, due to complicated parts or small cavities, any detergent residues may compromise the original product . The product is over 90% biodegradable.

Packaging

25 l cans

Part Number: 02098140

Product Properties

Appearance

Amber liquid

pH

(Sol. acq. 2%)
  10,5 ± 0,5

User Recommendations

NDT Method

Liquid penetrant inspection

Usage temperature

Up to 60°C

Usage concentration

From 2 to 5%

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Related products

Continue reading

Detergent Type Clean 19 AI

Technical datasheet

General description

CLEAN 19 AI Detergent is a non-foaming, non-flocculating cleaner that leaves no deposits on the nozzles. To be used by spraying. Ideal for the removal of oils, greases, machining dusts, fingerprints. Can also be used in single-stage machines without rinsing. Suitable for iron, steel, pure aluminium, copper and its alloys. If the cleaning process requires an ultrasonic immersion step, it must be added to a small quantity of CLEAN 84 HD.

Packaging

25 l cans

Part Number: 02098131

Product Properties

Appearance

Amber liquid

pH

(Sol. al 2%)
  7,5 ± 0,5

User Recommendations

NDT Method

Liquid penetrant inspection

Usage temperature

Up to 60°C

Usage concentration

From 2 to 5%

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Related products

Continue reading

Rotvel Avio Stick

Technical datasheet

General description

The Rotvel Avio Stick is a color contrast penetrant for high temperature controls with excellent resolution in detecting surface discontinuity indications. It generates an excellent red color contrast with good penetration characteristics. The penetrant is in the solid state; once in contact with the hot surface, it liquefies and penetrates into the possible discontinuities. For removal it is suggested to use a cloth soaked in Velemulsior H2O. Due to the remarkable penetrant fluidity , the formation of the indications is practically instantaneous after the application of the developer.

Packaging

Bags with 1 or more sticks

Part Number: 04099930

Features

  • Good penetration characteristics.

  • Intense and contrasting color.

  • Excellent discontinuities resolution.

Product Properties

Appearance

Opaque red solid

Method D
Sensitivity

Level 2

User Recommendations

NDT Method

High temperature dye liquid penetrat inspection


Usage temperature

From 50°C to 150°C

Recommended penetration time*

From 30 sec. to 3 min.

Developer

Rotrivel H2O Paste

Final cleaning

Velemulsior H2O

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Accessories EN ISO 3452

Stick holder

* For temperatures between 50°C and 80°C, the application time will be approximately 2-3 minutes. For temperatures between 80°C and 100°C, the application time will be approximately 1-2 minutes. For temperatures between 100°C and 150°C, the application time will be approximately 30 sec.-1 min.

Related products

Continue reading

CLT Group: our Partner for Telecommunications

CLT Group: our Partner for Telecommunications

 CLT Group has been providing for more than ten years now, the excellent service for CGM’s telephone and computer network. Thanks to their knowledge and professionalism, we can work with a convenient, fast and efficient system today.

Recently, Matteo Pettinari, our Technical Assistant Manager, was contacted by CLT Group for an interview, which formed the basis for the drafting of their new Case History article.

It was a pleasure for us to answer their questions and, by telling our experience and contribute in the creation of the newspaper article, which you can read at the below web site:

https://www.cltgroupsrl.it/cgm-cigiemme-spa/

Continue reading

Powder U 55+AC

Technical datasheet

General description

U 55+AC is a powder used for the preparation of a transparent water-based coupling gel, the viscosity of which can be adjusted according to the amount of water used. The gel obtained is suitable for the most common applications under normal conditions of use for both defect and thickness checks. It contains anti-corrosive so as not to affect the surfaces under examination. The product is non-toxic to skin, has no danger labelling and is not harmful to the environment.

Packaging

200 g envelope plastic bags

Part Number: 01049064

20 kg envelope plastic bags

Part Number: /

In Compliance with

  • ASME V Art.5 (T-533)

  • FAA AC 25-29 (glycerin free)

  • MIL-STD-271

  • RCC-MR

  • PMUC

Features

  • Excellent solubility in water.

  • It allows to obtain: an excellent couplant, suitable for different types of surfaces, with excellent lubricating properties for ultrasonic transducers.

Product Properties

Appearance

White powder

Recommended dilution in potable water

33 g/l

User Recommendations

NDT Method

Ultrasonic testing

Usage temperature

From 5°C to 80°C

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Related products

Continue reading
