General description
LA 150 is a ready-to-use suspension of fluorescent magnetic powder in water, for wet magnetic particle testing method. It is suitable for rough or unworked surfaces. The powder is characterized by particularly fluorescent pigments which allow it to be used in environments not totally darkened.
The suspension contains the anti-rust, surfactant, antifoam product Ata Fluid A44 and is totally nitrite-free.
LA 150 is a low-sulfur and low-halogen product, in compliance with standards.
Packaging
10 L cans | Part Number: 02087406 |
In Compliance with
-
EN ISO 9934-2 -
ASME V Art. 7
-
ASTM E709
-
ASTM E1444
-
AMS 3044
-
AS 4792
-
PMUC (certificate of compliance upon request)
Features
-
Excellent sensitivity. -
Good fluorescent contrast.
-
Good particle mobility.
-
Long-lasting particles.
Product Properties
Appearance | Green |
Color under UV light | Bright yellow-green |
Average particle size | 12 μm |
User Recommendations
NDT Method | Visible magnetic particle inspection, wet method |
Shelf life | 3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight |
Usage temperature | < 48°C |
Preliminary cleaning | Velnet/Solnet |
Recommended accessories according to standards ASTM E1444 ASTM E709 EN ISO 9934-2 | Sedimentation glass tube – Magnetic Stripe Card Type 2000 – Reference Block Type I / MTU Test – Reference Block Type II – Flexible Laminated Strips – Tool Steel Ring AS 5282 Type and Ketos 01 Type – Octagonal flat plate |
