General description

Magisglow 1 is a water washable fluorescent penetrant featuring excellent washability and has the lowest sensitivity level available in CGM’s range of fluorescent penetrants. It can be used in a wide variety of applications with good penetration characteristics and excellent reliability in identifying open surface defects with defect dimensions detectable using a 0.5 level penetrant.

Packaging

10 L cans
Part Number: 02041899
200 L metal drums
//

In Compliance with

  • ASME BPVC-V
  • ASTM E165/E165M-18
  • ASTM E1417/E1417M
  • EN ISO 3452-2
  • AMS 2644 (Complies with the standard, but not included in the QPL list)
  • PMUC (certificate of compliance upon request)

Features

  • Excellent penetration characteristics.
  • Intense and extremely bright color.
  • Excellent discontinuity resolution.
  • Wide range of applications.
  • Excellent washability.

Product Properties

Appearance
Yellow-green
Type / Method
Type 1 / Method A
Sensitivity
Level 0,5

User Recommendations

NDT Method
Water washable fluorescent liquid penetrant inspection
Usage temperature
From 4°C to 52°C
ASTM E165/UNI EN ISO 3452-1
Preliminary cleaning
Velnet/Solnet
Recommended penetration time*
From 10 to 20 min.
Developer
Rotrivel U − Velcontrast Dry Powder − Rotrivel H2O Paste
Final cleaning

Water – Velnet/Solnet – Detergent H2O

Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight

Accessories EN ISO 3452
Reference block type 1
Reference block type 2

* The times indicated refer to working temperatures between 10 and 52°C, for temperatures between 4 and 10°C the times indicated must be doubled.
