Rotrivel U

Technical datasheet

General description

Rotrivel U is a fast evaporating, non-halogenated solvent suspension developer that creates a matt white background for high contrast inspections. It can also be used to quickly verify the “bleeding”, in order to obtain sharp and clear indications.

Packaging

10 l cans
Part Number: 02011200
400 ml spray
Part Number: 03011210
200 l metal drums
//

In Compliance with

  • ASME V Art. 6
  • ASTM E165/E165M
  • ASTM E1417/E1417M
  • UNI EN ISO 3452-2 (Sensitivity level 4)
  • AMS 2644 (Complies with the standard, but not included in the QPL list)

Features

  • Milky white color.
  • Easy to apply.
  • Dries quickly.
  • Generates a very contrasting background.
  • Maximum sensitivity.
  • Easy to remove.

Product Properties

Milky white
Yellow-green
Type / Method
Method D – for Type 1 penetrants
Method E – for Type 2 and Type 3 penetrants
Flash point
≈ -20°C

User Recommendations

NDT Method
Color contrast and fluorescent liquid penetrant inspection
Shelf life
3 years at T between 0°C and 45°C
Usage temperature
From 0°C to 52°C
Cleaning
Velnet/Solnet
It can be used with all types of CGM penetrants
RED WW – Rotvel Avio B – Magisglow 3 – Magisglow 9 – Magisglow 17 – Magisglow 30 – GLOW 400 FWC …ecc.
