Wetting Agent A38

Technical datasheet

General description

Wetting Agent A38 is an excellent concentrated liquid defoamer and wetting agent for the conditioning of water-based magnetic particles suspensions.

Packaging

10 L cans Part Number: 02098020

Features

  • Easy to use.

  • Excellent defoam characteristics.

  • Excellent surface wetting.

  • Favors the dispersion of magnetic particles in the suspension.

Product Properties

Appearance Milky liquid
Dilution 0,5-1,0%
pH ISO 4316 6

User Recommendations

NDT Method Magnetic particle inspection
Shelf life 3 years at T between 5°C and 45°C
Usage temperature From 5°C to 55°C
Magnetic Particles K35-K40-K150-K755-K31.73
Preliminary cleaning Velnet/Solnet

Related products

Continue reading

Ata Fluid A44

Technical datasheet

General description

Ata Fluid A44 is an excellent defoam and anticorrosive concentrated liquid used for the conditioning of water-based magnetic particles suspensions.

It prevents the formation of algae and bacterial colonies.

Packaging

10 L cans Part Number: 02098050
200 L metal drums //

In Compliance with

AS 4792

Features

  • Easy to use.

  • Excellent defoam characteristics.

  • Excellent surface wetting.

  • Favors the dispersion of magnetic particles in the suspension.

  • Excellent short-term corrosion inhibition.

  • High anti-algae, fungicidal and antibacterial capacity.

Product Properties

Appearance Opalescent liquid
Dilution 0,5-1,0%
pH ISO 4316 9

User Recommendations

NDT Method Magnetic particle inspection
Shelf life 3 years at T between 5°C and 45°C
Usage temperature From 5°C to 55°C
Magnetic Particles K35-K40-K150-K755-K31.73
Preliminary cleaning Velnet/Solnet

Related products

Continue reading

Rust Inhibitor 1883

Technical datasheet

General description

The 1883 Rust Inhibitor Concentrate is an excellent water-miscible liquid product used when effective corrosion inhibition is required, without generating foam or causing significant alterations to the physical properties of the water itself.

Packaging

10 L cans Part Number: 02098074
200 L metal drums //

In Compliance with

AS 4792

Features

  • Easy to use.

  • Excellent corrosion inhibition.

  • Suitable for ferrous and non-ferrous metals.

  • Very low foam generation.

  • Highly resistant to microbial contamination.

Product Properties

Appearance Transparent amber liquid
Dilution 1,0-3,0%
pH ISO 4316 9

User Recommendations

NDT Method Magnetic particle inspection
Shelf life 3 years at T between 5°C and 45°C
Usage temperature From 5°C to 55°C
Magnetic Particles K35-K40-K150-K755-K31.73
Preliminary cleaning Velnet/Solnet

Related products

Continue reading

LA 755

Technical datasheet

General description

LA 755 is a ready-to-use suspension of fluorescent magnetic powder in water, for wet magnetic particle testing method. The powder is characterized by medium/small sized particles, suitable for surfaces with low and medium roughness.
The suspension contains the anti-rust, surfactant, antifoam product Ata Fluid A44 and is totally nitrite-free.

LA 755 is a low-sulfur and low-halogen product, in compliance with standards.

Packaging

10 L cans Part Number: 02087405

In Compliance with

  • EN ISO 9934-2

  • ASME V Art. 7

  • ASTM E709

  • ASTM E1444

  • AMS 3044

  • AS 4792

  • PMUC (certificate of compliance upon request)

Features

  • Excellent sensitivity.

  • Excellent fluorescent contrast.

  • Excellent particle mobility.

  • Long-lasting particles.

Product Properties

Appearance Green
Color under UV light Bright yellow-green
Average particle size 8 μm

User Recommendations

NDT Method Fluorescent magnetic particle testing, wet method
Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight
Usage temperature < 48°C
Preliminary cleaning Velnet/Solnet
Recommended accessories according to standards ASTM E1444 ASTM E709 EN ISO 9934-2

Sedimentation glass tube – Magnetic Stripe Card Type 2000 – Reference Block Type I / MTU Test – Reference Block Type II – Flexible Laminated Strips – Tool Steel Ring AS 5282 Type and Ketos 01 Type – Octagonal flat plate

Related products

Continue reading

LA 31.73

Technical datasheet

General description

LA 31-73 is a ready-to-use suspension of fluorescent magnetic powder in water, for wet magnetic particle testing method. Due to small size particles, this powder is very sensitive and particularly suitable for surfaces with low roughness.
The suspension contains the anti-rust, surfactant, antifoam product Ata Fluid A44 and is totally nitrite-free.

LA 31-73 is a low-sulfur and low-halogen product, in compliance with standards.

Packaging

10 L cans Part Number: 02087400

In Compliance with

  • EN ISO 9934-2

  • ASME V Art. 7

  • ASTM E709

  • ASTM E1444

  • AMS 3044

  • AS 4792

  • PMUC (certificate of compliance upon request)

Features

  • Excellent sensitivity.

  • Excellent fluorescent contrast.

  • Excellent particle mobility.

  • Long-lasting particles.

Product Properties

Appearance Green
Color under UV light Bright yellow-green
Average particle size 3 μm

User Recommendations

NDT Method Fluorescent magnetic particle testing, wet method
Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight
Usage temperature < 48°C
Preliminary cleaning Velnet/Solnet
Recommended accessories according to standards ASTM E1444 ASTM E709 EN ISO 9934-2

Sedimentation glass tube – Magnetic Stripe Card Type 2000 – Reference Block Type I / MTU Test – Reference Block Type II – Flexible Laminated Strips – Tool Steel Ring AS 5282 Type and Ketos 01 Type – Octagonal flat plate

Related products

Continue reading

LA 150

Technical datasheet

General description

LA 150 is a ready-to-use suspension of fluorescent magnetic powder in water, for wet magnetic particle testing method. It is suitable for rough or unworked surfaces. The powder is characterized by particularly fluorescent pigments which allow it to be used in environments not totally darkened.
The suspension contains the anti-rust, surfactant, antifoam product Ata Fluid A44 and is totally nitrite-free.

LA 150 is a low-sulfur and low-halogen product, in compliance with standards.

Packaging

10 L cans Part Number: 02087406

In Compliance with

  • EN ISO 9934-2

  • ASME V Art. 7

  • ASTM E709

  • ASTM E1444

  • AMS 3044

  • AS 4792

  • PMUC (certificate of compliance upon request)

Features

  • Excellent sensitivity.

  • Good fluorescent contrast.

  • Good particle mobility.

  • Long-lasting particles.

Product Properties

Appearance Green
Color under UV light Bright yellow-green
Average particle size 12 μm

User Recommendations

NDT Method Visible magnetic particle inspection, wet method
Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight
Usage temperature < 48°C
Preliminary cleaning Velnet/Solnet
Recommended accessories according to standards ASTM E1444 ASTM E709 EN ISO 9934-2

Sedimentation glass tube – Magnetic Stripe Card Type 2000 – Reference Block Type I / MTU Test – Reference Block Type II – Flexible Laminated Strips – Tool Steel Ring AS 5282 Type and Ketos 01 Type – Octagonal flat plate

Related products

Continue reading

PKD 755/50

Technical datasheet

General description

PKD 755/50 is a fluorescent magnetic powder concentrate in petroleum used to prepare suspensions for wet magnetic particle testing.
PKD 755/50 concentrate must be suspended in a liquid vehicle based on petroleum distillates, such as Kerosenoil. The powder is characterised by medium/small particle size and is therefore suitable for low to medium roughness surfaces.

PKD 755/50 is a low-sulfur and low-halogen product, in compliance with standards.

Packaging

0,5 L cans Part Number: 01036406

In Compliance with

  • EN ISO 9934-2

  • ASME V Art. 7

  • ASTM E709

  • ASTM E1444

  • AMS 3044

  • PMUC (certificate of compliance upon request)

Features

  • It must be suspended in oil (Kerosenoil).

  • Almost odorless.

  • Excellent sensitivity.

  • Excellent fluorescent contrast.

  • Excellent particle mobility.

  • Long-lasting particles.

  • Easily dispersible.

Product Properties

Appearance Green
Color under UV light Bright yellow-green
Average particle size 8 μm

User Recommendations

NDT Method Fluorescent magnetic particle testing, wet method
Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight
Usage temperature < 48°C
Suspension vehicle Kerosenoil
Wetting agent for water baths Ata Fluid A44 or Wetting Agent A38
Preliminary cleaning Velnet/Solnet
Recommended accessories according to standards ASTM E1444 ASTM E709 EN ISO 9934-2

Sedimentation glass tube – Magnetic Stripe Card Type 2000 – Reference Block Type I / MTU Test – Reference Block Type II – Flexible Laminated Strips – Tool Steel Ring AS 5282 Type and Ketos 01 Type – Octagonal flat plate

Related products

Continue reading

PKD 31-73/50

Technical datasheet

General description

PKD 31-73/50 is a fluorescent magnetic powder concentrate in petroleum used to prepare suspensions for wet magnetic particle testing.
PKD 31-73/50 concentrate must be suspended in a liquid vehicle based on petroleum distillates, such as Kerosenoil. Due to small size particles, this powder is very sensitive and particularly suitable for surfaces with low roughness.

PKD 31-73/50 is a low-sulfur and low-halogen product, in compliance with standards.

Packaging

0,5 L cans Part Number: 01036410

In Compliance with

  • EN ISO 9934-2

  • ASME V Art. 7

  • ASTM E709

  • ASTM E1444

  • AMS 3044

  • PMUC (certificate of compliance upon request)

Features

  • It must be suspended in oil (Kerosenoil).

  • Almost odorless.

  • Super sensitivity.

  • Excellent fluorescent contrast.

  • Excellent particle mobility.

  • Long-lasting particles.

  • Easily dispersible.

Product Properties

Appearance Green
Color under UV light Bright yellow-green
Average particle size 3 μm

User Recommendations

NDT Method Fluorescent magnetic particle testing, wet method
Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight
Usage temperature < 48°C
Suspension vehicle Kerosenoil
Preliminary cleaning Velnet/Solnet
Recommended accessories according to standards ASTM E1444 ASTM E709 EN ISO 9934-2

Sedimentation glass tube – Magnetic Stripe Card Type 2000 – Reference Block Type I / MTU Test – Reference Block Type II – Flexible Laminated Strips –Tool Steel Ring AS 5282 Type and Ketos 01 Type – Octagonal flat plate

Related products

Continue reading

PKD 35/50

Technical datasheet

General description

PKD 35/50 is a black magnetic powder concentrate in petroleum used to prepare suspensions for wet magnetic particle testing.
PKD 35/50 concentrate should be suspended in a petroleum (oil) based liquid carrier, such as Kerosenoil.

PKD 35/50 is a low-sulfur and low-halogen product, in compliance with standards.

Packaging

1 L cans Part Number: 01036416

In Compliance with

  • EN ISO 9934-2

  • ASME V Art. 7

  • ASTM E709

  • ASTM E1444

  • AMS 3042

  • PMUC (certificate of compliance upon request)

Features

  • It must be suspended in oil (Kerosenoil).

  • Almost odorless.

  • Excellent sensitivity.

  • Excellent fluorescent contrast.

  • Excellent particle mobility.

  • Long-lasting particles.

  • Easily dispersible.

Product Properties

Appearance Black
Color under UV light NA
Average particle size 1 μm

User Recommendations

NDT Method Visible magnetic particle inspection, wet method
Shelf life

3 years at T between 5°C and 45°C, in a dry place safe from direct sunlight
Usage temperature < 48°C
Suspension vehicle Kerosenoil
Preliminary cleaning Velnet/Solnet
Contrast paint Vecoplast
Recommended accessories according to standards ASTM E1444 ASTM E709 EN ISO 9934-2

Sedimentation glass tube – Magnetic Stripe Card Type 2000 – Reference Block Type I / MTU Test – Reference Block Type II – Flexible Laminated Strips – Tool Steel Ring AS 5282 Type and Ketos 01 Type – Octagonal flat plate

Related products

Continue reading
